Name: Siemens Universal Controller RWD62
SKU: 3445
Availability: InStock

Siemens Universal Controller RWD62

$344.00

The universal controllers are intended for Heating, Ventilating, Air-Conditioning and Refrigeration in comfort control plants. It can be mounted in a control panel or in theARG62.21/ARG62.22 housing on ducts, walls and in plant rooms.

Measurement and control of temperature, relative humidity, absolute humidity, enthalpy, pressure differential, volumetric airflow and indoor air quality. The input scale can be set from –100 units to 8,000 units. The start and end points of output voltage can be any value between 0 V DC to 10 V DC

Siemens Universal Controller RWD62

Standalone electronic universal controller with P or PI response
Operating voltage in accordance to type AC 24 V
Control application selectable via Application Number
Active input scale can be selectable
Limit & direction of the output scale is able to be freely assigned
Two universal inputs for Ni 1000, Pt 1000 temperature sensors &0…10 V signals
Unit can be set as ºC, ºF, % or no specified unit
Two modulating outputs with DC 0…10 V signal outputs, direct or reverse action
One digital input for day / night changeover
Entering or changing of all data via operating buttons on the controller, possible without additional tools
PC connection for downloading canned applications via the software tool
